Hydraulic filter elements are designed for removing dirt and particles in hydraulic systems. These replacement filter elements are used with portable hydraulic filtration carts to replace
...Read more
A
B
A
B
C
A
BCHydraulic filter elements are ideal for removing metal pieces, dust particles or unwanted chemicals from a hydraulic system that comes either from ingestion through the reservoirs of hydraulic system components or by the internal generation of the particles from motors or pumps. These hydraulic filter elements are used with portable hydraulic filtration carts in mining, marine, agriculture, automobile & construction industries for excellent filtration and flow rates. These hydraulic filter elements can be installed either in between pumps & actuators or between tanks & actuators. Hydraulic filter elements also reduce equipment or system downtime and increase operating profitability.
Hydraulic filter elements are used to clean fluids and extend the life of hydraulic systems. These hydraulic filter elements are suitable for injection moulding, oil patch drilling equipment and hydrostatic drive charge pumps for filtering out contaminants.
Low Pressure Filter Moduflow Plus Series hydraulic filter elements
CN Series hydraulic filter elements
A wide range of these hydraulic filter elements are available in 10 & 20 micron variants on Raptor Supplies, a trusted Parker hydraulic filter elements Supplier.
As fluid flows through the filter element, dust particles or unwanted chemicals are trapped by the media. Simultaneously, the fluid develops a differential pressure between the inlet and outlet. The spring present in the hydraulic system holds the bypass piston and senses the pressure difference. As the differential pressure reaches a specific threshold, the indicator switches ON to indicate the need for cleaning or replacement. As the perforated protective cage around filter mats connects to the two end discs, it will allow the fluids to flow freely and continuously in the hydraulic filter element. Now, when the fluid flows through the mat, the protective cage will protect from any external damages. The attached seal rings or profile seals will seal the space between the filter element and filter housing, thus stopping or reducing the leakage occurring from the hydraulic filter element. As fluid continues flowing, more & more contaminants remain in hydraulic filter elements, and thus the clean hydraulic fluid will flow out through the outlet into the hydraulic system.
Hydraulic filter elements are found in most hydraulic systems, generally between the pump and tank, in line with the return flow to the hydraulic tank.
Hydraulic filters are integral parts of a hydraulic system that eliminate contaminants from emulsions and oils. These filters are ideal for filtering hydraulic fluids in a hydraulic system while charging fluid, adding a new fluid or flushing the hydraulic system before adding new fluid. They also help in actuating a hydraulic cylinder.
Normally, hydraulic filters should be changed when the dirt holding capacity of the filter is about 80% full before the filter goes on bypass.
