What standards do weld studs comply with?

ASTM A108, ASTM A276, ASTM A29 & ASTM A493.

What is stud welding?

The studs are permanently attached to one side of a workpiece while the other side is left undamaged by the stud welding procedure. A suitable stud welding gun accepts the weld stud, which is then fed current by a stud welder through the gun. The workpiece and the base of the stud are melted by the current, fusing them together to form a weld.

We are closed from Monday, Dec 23rd and will reopen on Monday, Jan 6th. Any orders received during this time will be processed in the New Year.

Weld Studs

Filter

Weld studs are welded onto metal sheets for attaching parts & components to the base metal sheet for automotive & metalworking applications. Raptor Supplies offers a wide array of...Read more

APPROVED VENDOR -

Weld Stud 1/4-20 inch

Style	Model	Head Dia.	Length under Head	Thread Length	Type	Price (ex. VAT)
A	1LAP2	0.498"	27/64"	0.422"	Top Projection	€14.95
A	1LAP3	0.498"	43/64"	0.672"	Top Projection	€22.66
B	1LAL8	0.563"	3/4"	0.71"	Bottom Projection	€38.93
B	1LAN1	0.563"	1"	0.96"	Bottom Projection	€44.92
B	1LAN2	0.563"	1.25"	1.21"	Bottom Projection	€47.09
B	1LAL5	0.563"	3/8"	0.335"	Bottom Projection	€29.13
B	1LAL6	0.563"	1/2"	0.46"	Bottom Projection	€36.48
B	1LAL7	0.563"	5/8"	0.585"	Bottom Projection	€34.03
B	1LAL9	0.563"	7/8"	0.835"	Bottom Projection	€42.19

NELSON STUD WELDING INC. -

Welding Studs

Style	Model	Finish	Head Dia.	Head Height	Item	Length under Head	Material	Thread Direction	Thread Length	Price (ex. VAT)
A	101-208-278-G1000	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	1"	Mild Steel	RH	1"	€151.42
A	101-208-278-G100	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	1"	Mild Steel	RH	1"	€17.67
A	101-208-217-G1000	Copper Plated	0.218"	-	Cap. Discharge Welding Stud	3/8"	Mild Steel	RH	3/8"	€90.73
A	101-208-234-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	€13.18
A	101-208-218-G1000	Copper Plated	0.218"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€89.45
A	101-208-232-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€12.53
A	101-208-275-G100	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	5/8"	Mild Steel	RH	5/8"	-	RFQ
A	101-208-274-G100	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€14.17
A	101-208-260-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€12.97
A	101-208-262-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	-	RFQ
A	101-208-231-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/8"	Mild Steel	RH	3/8"	€11.83
A	101-208-218-G100	Copper Plated	0.218"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€12.06
A	101-208-233-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	5/8"	Mild Steel	RH	5/8"	€108.12
A	101-208-276-G1000	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	€139.86
A	101-208-276-G100	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	€17.45
A	101-208-274-G1000	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€110.52
A	101-208-233-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	5/8"	Mild Steel	RH	5/8"	€12.85
A	101-208-259-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/8"	Mild Steel	RH	3/8"	-	RFQ
A	101-208-234-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	-	RFQ
A	101-208-259-G100	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/8"	Mild Steel	RH	3/8"	-	RFQ
A	101-208-262-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/4"	Mild Steel	RH	3/4"	-	RFQ
A	101-208-275-G1000	Copper Plated	0.312"	-	Cap. Discharge Welding Stud	5/8"	Mild Steel	RH	5/8"	-	RFQ
A	101-208-260-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€101.20
A	101-208-232-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	1/2"	Mild Steel	RH	1/2"	€98.62
A	101-208-231-G1000	Copper Plated	0.250"	-	Cap. Discharge Welding Stud	3/8"	Mild Steel	RH	3/8"	€92.75

NELSON STUD WELDING INC. -

Chucks

Style	Model	Size	Type	Price (ex. VAT)
A	500-001-356	#6	#6 NCD	€69.31
A	500-001-357	#8	#8 NCD	€64.54
A	500-001-366	#10	#10 NCD	€62.49
B	500-001-014	1/2-13	1/2-13 for Standard Stud Weld Guns	€112.78
A	500-001-359	1/4"	1/4" NCD	€64.54
B	500-001-007	1/4-20	1/4-20 for Standard Stud Weld Guns	€81.21
B	500-001-011	3/8"	3/8 for Standard Stud Weld Guns	€119.51
B	500-001-016	5/8-11	5/8-11 for Standard Stud Weld Guns	€145.67
B	500-001-009	5/16-18	5/16-18 for Standard Stud Weld Guns	€84.57

APPROVED VENDOR -

Weld Stud

Style	Model	Head Dia.	Head Height	Length under Head	Thread Length	Thread Size	Type	Price (ex. VAT)
A	1LAP1	0.375"	0.063"	7/16"	0.437"	10-24	Top Projection	€14.45
B	1LAK9	0.438"	0.063"	1/2"	0.47"	10-24	Bottom Projection	€16.01
B	1LAK8	0.438"	0.063"	3/8"	0.345"	10-24	Bottom Projection	€17.37
B	1LAL1	0.438"	0.063"	3/4"	0.72"	10-24	Bottom Projection	€22.32
B	1LAN7	0.865"	0.109"	1"	0.95"	3/8-16	Bottom Projection	€105.47
B	1LAN8	0.865"	0.109"	1.25"	1.2"	3/8-16	Bottom Projection	€119.34

APPROVED VENDOR -

Weld Stud 10-32 Thread

Style	Model	Length under Head	Thread Length	Price (ex. VAT)
A	1LAL4	1"	0.97"	€6.34
A	1LAL2	1/2"	0.47"	€5.37
A	1LAL3	5/8"	0.595"	€5.44

NELSON STUD WELDING INC. -

Ferrule Grips

Style	Model	Size	Type	Price (ex. VAT)
A	501-001-009	1/2"	1/2" for Drawn Arc Equipment	€18.58
A	501-001-005	1/4"	1/4" for Drawn Arc Equipment	€22.70
A	501-001-007	3/8"	3/8" for Drawn Arc Equipment	€24.97
A	501-001-011	5/8"	5/8" for Drawn Arc Equipment	€35.24
A	501-001-006	5/16"	5/16" for Drawn Arc Equipment	€22.70

VULCAN HART -

Weld Studs

Style	Model	Price (ex. VAT)
A	00-911035-00004	€0.54	RFQ
A	720139	-	RFQ

APPROVED VENDOR -

Weld Stud 5/16-18

Style	Model	Head Dia.	Length under Head	Thread Length	Type	Price (ex. VAT)
A	1LAP4	0.618"	21/32"	0.63"	Top Projection	€5.05
B	1LAN4	0.740"	3/4"	0.68"	Bottom Projection	€19.07
B	1LAN5	0.740"	1"	0.955"	Bottom Projection	€57.37
B	1LAN6	0.740"	2"	1.955"	Bottom Projection	€90.74
B	1LAN3	0.740"	5/8"	0.58"	Bottom Projection	€52.27

NELSON STUD WELDING INC. -

Back Up Pins

Style	Model	Size	Type	Price (ex. VAT)
A	500-017-019	1 1/4 to 1 5/8"	1 1/4 to 1 5/8" for NCD Series Stud Welding Guns	€20.85
A	500-017-020	1 3/4 to 2 1/8"	1 3/4 to 2 1/8" for NCD Series Stud Welding Guns	€22.07
A	500-017-017	1/4 to 5/8"	1/4 to 5/8" for NCD Series Stud Welding Guns	€31.12
A	500-017-018	3/4 to 1 1/8"	3/4 to 1 1/8" for NCD Series Stud Welding Guns	€22.43

VULCAN HART -

Studs

Style	Model	Height	Length	Width	Price (ex. VAT)
A	00-417852-00001	-	-	-	-	RFQ
A	718279	-	-	-	-	RFQ
A	00-821838-00001	-	-	-	-	RFQ
B	00-417852-00003	0.25"	0.3"	2.4"	€9.06	RFQ
C	00-817024	0.65"	1.6"	2.95"	€4.94	RFQ
D	00-413785-00001	0.85"	2.4"	4.2"	€15.64	RFQ

APPROVED VENDOR -

Weld Stud 8-32 Thread

Style	Model	Length under Head	Thread Length	Price (ex. VAT)
A	1LAK7	1"	0.975"	€19.44
A	1LAK6	3/4"	0.725"	€18.24
A	1LAK5	3/8"	0.35"	€15.73

APPROVED VENDOR -

Weld Stud, Right-angle

Style	Model	Thread Length	Thread Size	Thread Type	Price (ex. VAT)
A	1LAP6	0.312"	8-32	UNC	€21.55
A	1LAR3	0.406"	1/4-20	UNC	€16.16
A	1LAP7	0.437"	8-32	UNC	€23.88
A	1LAP8	0.437"	10-24	UNC	€22.77
A	1LAR2	0.437"	10-32	UNF	€24.98
A	1LAP5	0.453"	6-32	UNC	€15.26
A	1LAR4	0.531"	1/4-20	UNC	€16.90
A	1LAR5	0.656"	1/4-20	UNC	€15.54
A	1LAP9	0.687"	10-24	UNC	€22.87
A	1LAR6	0.906"	1/4-20	UNC	€17.77

APPROVED VENDOR -

Weld Stud 6-32 X 0.605 Inch, 100PK

Model	Item	Price (ex. VAT)
1LAK4	AB2CVC	€16.06

APPROVED VENDOR -

Weld Stud 1/2-13 X 1.190 Inch, 100PK

Model	Item	Price (ex. VAT)
1LAN9	AB2CWC	€47.04

Weld Studs

Weld studs are welded onto metal sheets for attaching parts & components to the base metal sheet for automotive & metalworking applications. Raptor Supplies offers a wide array of weld studs featuring copper alloy / mild steel / stainless steel / steel construction for impact strength & mildly magnetic properties. These weld studs are manufactured by Nelson & Vulcan Hart.
