DAYTON Compact Submersible Pumps
Compact Submersible Pumps
DAYTON
Dayton compact submersible pumps are suitable for vaporisers, evaporative coolers & fountains for condensate removal and machine coolant recirculation. They are sealed in oil for permanent lubrication and feature an epoxy coated motor case for corrosion protection. These pumps deliver a maximum speed of 3400 rpm, provide viscosity up to 100 SSU and are integrated with viton / nitrile seals for resistance against oils & abrasives. Choose from a wide range of these compact submersible pumps, available in acetal, POM and zinc alloy housing variants.
More Information
Ship Pack Width (in)7.8
Ship Pack Length (in)11.8
Ship Pack Height (in)5.9
BrandDAYTON
Harmonization Code8413702004
Model No12U595
Gph Of Water @ 1 Ft. Of Head301
Full Load Watts85
Equivalent Psi3.2
Pump MaterialZinc Alloy
Overload ProtectionAutomatic
Motor Housing MaterialZinc alloy
Max. Gpm For Water5
Gph Of Water @ 5 Ft. Of Head218
Width4.88"
Volute MaterialPOM
Voltage115V
Shaft Material420 Stainless Steel
Seal MaterialNitrile
Screen MaterialPolyamide Fibre 56
Outlet Size1/4" NPT
Motor TypeShaded Pole
Motor Rpm3400
Length4.75"
Inlet Type1/2" NPT/Screen
Impeller MaterialPolyamide Fibre 56
Hp1/100
Housing MaterialPOM
Height4.75"
DutyContinuous
Cord Length6ft.
Cord Type3-Conductor SJTOW, Resists Water and Oil
ItemCompact Submersible Pump
Full Load Amps1.4
Hz60
Inlet1/2" NPT/Screen
Outlet1/4" (M)NPT
Max. Viscosity100 SSU
