GENERAL ELECTRIC Lighting Contactor

What are the main components of a GE lighting contactor?

GE lighting contactor consists of a coil, a set of contacts (usually NO - normally open), an auxiliary contact set (for signalling or control purposes) and a housing to protect the components.

How to maintain these GE lighting contactors?

• Regularly inspect the contactor for wear and loose connections.
• Clean contact surfaces to remove dust and debris.
• Tighten all electrical connections to ensure security.
• Check the coil for damage and verify control circuit protection.
• Replace damaged or worn components with genuine parts.
• Maintain records of maintenance activities for reference.
• Adhere to safety precautions and use appropriate PPE during maintenance tasks.

Can GE lighting contactors be integrated into building automation systems?

Yes, GE lighting contactors can often be integrated into building management and automation systems, allowing for centralised control & monitoring of lighting.

How do I install these GE lighting contractors?

• Turn off power to the circuit before beginning installation.
• Securely mount the contactor in a well-ventilated location.
• Wire the incoming power supply to line-side terminals as per the diagram.
• Connect lighting fixtures or devices to the load-side terminals.
• Wire the control circuit to the contactor's coil with proper protection.
• Ensure the contactor is grounded for safety.
