| Item | Condenser Fan Motor |
| Bearings | Ball |
| Body Dia. | 5.625" |
| Bolt Circle Dia. | 7" |
| Capacitor Required | 2MDY7 |
| Duty | Continuous Air-Over |
| Enclosure | Open Air-Over |
| Frame | 48Y |
| Frequency | 60 Hz |
| Full Load Amps | 4.6-4.6/2.3 |
| Hp | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Lead Length | 5" to 6" |
| Length Less Shaft | 7.25" |
| Max. Ambient Temp. | 60 Degrees C |
| Motor Application | H Vac/R |
| Motor Design | Permanent Split Capacitor |
| Motor Enclosure Design | Open Air-Over |
| Motor Mounting Type | Lug |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Condenser Fan |
| Motor Thermal Protection | Auto |
| Motor Type | PSC |
| Mounting | Lug |
| Nameplate Rpm | 1075 |
| Number Of Speeds | 1 |
| Overall Length | 9.75" |
| Phase | 1 |
| Replacement For | 230 |
| Rotation | CW/CCW |
| Rpm Range | 1001-1100 |
| Service Factor | 1.0 |
| Shaft Dia. | 1/2" |
| Shaft Length | 2.5" |
| Shaft Orientation | Vertical |
| Shaft Type | Flat |
| Thermal Protection | Auto |
| Voltage | 200-230/460 |
| Ship weight (kg) | 9.45 |
| Ship height (cm) | 23.11 |
| Ship length (cm) | 25.91 |
| Ship width (cm) | 30.99 |
| HS code | 8501404040 |
| Country of Origin | IN |
