| Aircraft Drill | No |
| Coolant Fed | Non Coolant Through |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.026 , 0.026" |
| Depth X Dia. Ratio | 4Xd |
| Drill Bit Point Angle | 118° |
| Drill Bit Point Type | Conventional Point |
| Drill Bit Size | #71 |
| Drill Diameter Tolerance | -0.0005" to 0" |
| Drill Length Class | Jobber Length |
| Drill Point Length | 0.008" |
| Finish | Black Oxide |
| Flute Length | 3/8" |
| Flute Type | Spiral |
| Grade | High Performance |
| Helix Angle | 21° to 34° |
| Material | High Speed Steel |
| Max. Drilling Depth | 0.281" |
| Mfr. Series | 2001 |
| Number Of Coolant Holes | 0 |
| Number Of Flutes | 2 |
| Overall Length | 1 1/4" |
| Primary Material Application | Cast Iron, Steel |
| Shank Length | 7/8" |
| Shank Type | Straight |
| Sheeter Drill | No |
| Spiral Direction | Right Hand |
| Web Thinning | Thinned |
| Ship weight (kg) | 0.0004 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 8.51 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
