| Item | General Purpose Motor |
| Bearings | Ball |
| Capacitor Required | Yes |
| Duty | Continuous |
| Efficiency | 76.2% |
| Efficiency Group | NEMA Premium(R) |
| Frame | 48Z |
| Frame Material | Rolled Steel |
| Full Load Amps | 6.4/3.2 |
| Green Certification Or Other Recognition | Energy Aware |
| Hp | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Inverter Rated | No |
| Length Less Shaft | 8.375" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Design | Capacitor-Start/Run |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Cradle Base |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | Clockwise, Counter Clockwise |
| Motor Thermal Protection | Auto |
| Nameplate Rpm | 1725 |
| Nominal Efficiency | 76.2% |
| Number Of Speeds | 1 |
| Overall Length | 10 5/16" |
| Phase | 1 |
| Rpm Group | 1701-1800 |
| Rpm Range | 1701-1800 |
| Service Factor | 1.25 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1.875" |
| Voltage | 115/230 |
| Warranty | 1 Years |
| Ship weight (kg) | 9.405 |
| Ship height (cm) | 27.18 |
| Ship length (cm) | 38.61 |
| Ship width (cm) | 21.08 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Efficiency Group | Frame | Frame Material | Full Load Amps | HP | Insulation Class | Length Less Shaft | Motor Mounting Position | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20CL53 | Energy Efficient | 48 | Steel | 4.4/2.4-2.2 | 1/2 | B | 9" | Horizontal or Vertical Shaft Down | €421.47 | |
 |
30PT69 | NEMA Premium(R) | 56 | Rolled Steel | 7.0/3.5 | 3/4 | B | 10.375" | Horizontal | €474.16 | |
 |
30PT70 | NEMA Premium(R) | 56 | Rolled Steel | 7.0/3.5 | 3/4 | B | 10.375" | Horizontal | €518.22 | |
 |
30PT71 | NEMA Premium(R) | 56H | Rolled Steel | 7.0/3.5 | 3/4 | B | 10.375" | Horizontal | €446.49 | |
 |
30PT38 | NEMA Premium(R) | 56C | Rolled Steel | 3.1/1.5 | 1/4 | B | 7.875" | Horizontal | €363.06 | |
 |
30PT40 | NEMA Premium(R) | 56C | Rolled Steel | 6.4/3.2 | 1/2 | B | 7.875" | Horizontal | €570.00 | |
 |
30PT41 | NEMA Premium(R) | 56C | Rolled Steel | 7.0/3.5 | 3/4 | B | 9.875 | Horizontal | €638.77 |
