| Item | Condenser Fan Motor |
| Bearings | Ball |
| Body Dia. | 6.5" |
| Bolt Circle Dia. | 5.875" |
| Capacitor Required | No |
| Duty | Continuous |
| Frame | 56Z |
| Frequency | 60 Hz |
| Full Load Amps | 2.8-2.8/1.4 |
| Hp | 3/4 |
| Hz | 60 |
| Insulation Class | F |
| Lead Length | 6" |
| Length Less Shaft | 8.75" |
| Max. Ambient Temp. | 60 Degrees C |
| Motor Application | Condenser Fan |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Open Air-Over |
| Motor Mounting Position | Horizontal or Vertical Shaft Up |
| Motor Mounting Type | Band |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Sub Application | Condenser Fans |
| Motor Thermal Protection | Auto |
| Nameplate Rpm | 1140 |
| Nominal Efficiency | 82.0% |
| Number Of Speeds | 1 |
| Overall Length | 14.75" |
| Phase | 3 |
| Rpm Range | 1001-1100 |
| Service Factor | 1.00 |
| Shaft Dia. | 5/8" |
| Shaft Length | 6" |
| Stud Pattern | 4-1/8 x 4-1/8" |
| Stud Quantity | 4 |
| Stud Size | 10-32" |
| Voltage | 208-230/460 |
| Ship weight (kg) | 14.175 |
| Ship height (cm) | 27.69 |
| Ship length (cm) | 46.99 |
| Ship width (cm) | 26.67 |
| HS code | 8501514040 |
| Product | Model | Body Dia. | Duty | Enclosure | Frame | Full Load Amps | HP | Length Less Shaft | Max. Ambient Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
24PR70 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 5.2-5.2/2.6 | 1 | 10.25" | 60 Degrees C | €891.42 | |
 |
24PR71 | 5.625" | Continuous Air-Over | Open Air- Over | 56YZ | 5.0-5.0/2.5 | 1 | 10.75" | 70 Degrees C | €846.18 | |
 |
24PR72 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 4.3-4.3/2.1 | 1 | 9.75" | 70 Degrees C | €467.84 | |
 |
24PR73 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 7.2-7.2/3.6 | 1.5 | 12.25" | 60 Degrees C | €898.55 | |
 |
24PR74 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 5.3-5.3/2.6 | 1.5 | 10.25" | 70 Degrees C | €706.04 | |
 |
24PR75 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 7.8-7.8/3.9 | 2 | 10.75" | 70 Degrees C | €555.03 | |
 |
24PR76 | 5.625" | Continuous Air-Over | Open Air-Over | 56YZ | 3.1/1.6 | 1/2 | 10.75" | 60 Degrees C | €891.72 |
