| Item | General Purpose Motor |
| Bearings | Ball |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Efficiency | 61.4% |
| Frame | 48Z |
| Frame Material | Steel |
| Full Load Amps | 5.9A |
| Hp | 1/3 hp |
| Hz | 60 Hz |
| Includes | conduit box |
| Insulation Class | Class B |
| Length Less Shaft | 9 1/8" |
| Max. Ambient Temp. | 104°F |
| Motor Application | General Application |
| Motor Design | Split-Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Type | Cradle Base |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | Clockwise, Counter Clockwise |
| Motor Thermal Protection | None |
| Motor Type | Split Phase |
| Mounting | Cradle Base |
| Nameplate Rpm | 1725 RPM |
| Number Of Speeds | 1 |
| Overall Length | 11" |
| Phase | 1 |
| Rotation | CW/CCW |
| Rpm Group | 1701-1800 |
| Rpm Range | 1701-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1 7/8" |
| Thermal Protection | None |
| Voltage | 115V AC |
| Warranty | 1 yr. |
| Ship weight (kg) | 8.8875 |
| Ship height (cm) | 27.69 |
| Ship length (cm) | 40.89 |
| Ship width (cm) | 27.94 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Capacitor Required | Efficiency Group | Frame | Frame Material | Full Load Amps | Green Certification or Other Recognition | HP | Hz | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
2TJ12 | - | - | 184T | Steel | 20.5 | - | 5 | 60 | €1,199.02 | |
 |
5GD60 | - | - | 56C | Steel | 11.0/5.4-5.5 | - | 3/4 | 60 | €464.03 | |
 |
5K596BE | - | - | 56 | Rolled Steel | 8.0 | - | 1/2 | 60 | €327.52 | |
|
5K618BE | - | - | 56 | Rolled Steel | 7.2/5.0 | - | 1/2, 1/4 | 60 | €421.85 | |
 |
5K968 | - | - | 213T | Steel | 20.5 | - | 5 | 60 | €1,699.88 | |
 |
5PHA7 | - | - | 56 | Rolled Steel | 10.1/5.1 | - | 3/4 | 60 | €414.40 | |
 |
5UKH0 | - | - | 215T | Steel | 41.5 | - | 10 | 60 | €2,589.28 |
