| Item | Sensor |
| Case Material | Polybutylene Terephthalate |
| Connector Size | M8 x 1 |
| Connector Type | 4 Pin |
| Contact Type | S/S |
| Control | Frontal |
| Fastening Type | Screwed From Above |
| Housing Color | Black |
| Housing Design | Cuboid |
| Installation Opening | 4.5 mm |
| Ip Rating | Ip67 |
| Led Display | No |
| Max. Operating Temp. | 75 Deg. C |
| Max. Storage Temp. | 75 Deg. C |
| Max. Switching Current | 0.1A |
| Max. Switching Voltage | 28.8V DC |
| Min. Operating Temp. | -25 Deg. C |
| Min. Storage Temp. | -25 Deg. C |
| Min. Switching Voltage | 19.2V DC |
| Minimum Switching Distance | 0.5 mm |
| Non Flush Mountable | Yes |
| Safe Switch-off Distance | 10 mm |
| Safe Switching Distance | 3 mm |
| Series Resistor | 22 Ohm |
| Size | 36 mm x 26 mm x 13 mm |
| Structure | Two-Channel |
| Switching Principle | Magnetic |
| Technology | Reed |
| Model | Actuation Frequency | Actuation Type | Assured Switch Off Distance | Assured Switching Distance | Cable Length | Cable Material | Cable Size | Cannot Be Mounted Flush | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 171V62AY | - | Front | 16 mm | 4 mm | - | - | - | Yes | - | RFQ
|
| 114270A0D | - | Front | 19 mm | 7 mm | - | - | - | - | - | RFQ
|
| 171V62VY | - | Front | 16 mm | 4 mm | - | - | - | Yes | - | RFQ
|
| 114270-5 | - | Front | 19 mm | 7 mm | 1 m | PVC | - | - | - | RFQ
|
| 153V62-10 | - | - | - | - | - | - | - | - | - | RFQ
|
| 165270-5 | - | - | - | - | 1 m | PVC | - | - | - | RFQ
|
| 120272-5 | - | Front | 22 mm | 4 mm | 1 m | PVC | - | - | - | RFQ
|
