| Amps | 5A |
| Application | Drilling |
| Base Length | 10" |
| Base Width | 16 1/8" |
| Chuck Capacity | 5/8" |
| Chuck Size | 5/8" |
| Chuck Style | Keyed |
| Column Dia. | 2 1/2" |
| Coolant System | No |
| Drill Press Type | Benchtop |
| Drilling Capacity In Wood | 2" |
| Drilling Capacity Steel | 1/2" |
| Drive Type | Belt |
| Guard Included | No |
| Hp | 1/2 hp |
| Includes | Arbor, Drift Key, Keyed Chuck |
| Length | 29 3/4" |
| Max. Overall Height | 12 1/4" |
| Max. Spindle Speed | 3100 RPM |
| Maximum Spindle To Base Height | 23 3/8" |
| Maximum Spindle To Table Height | 17" |
| Min. Spindle Speed | 530 RPM |
| Number Of Speeds | Variable |
| Number Of Spindle Speeds | Variable |
| Number Of T-slots | 4 |
| Phase | 1 |
| Power Downfeed Included | No |
| Power Source | Corded |
| Primary Material Application | Metal, Wood |
| Quill Dia. | 1 5/8" |
| Radial Arm | No |
| Speed Adjustment | Mechanical Variable Speed Drive System |
| Speed Control | Variable |
| Speed Range | 530-3100 RPM |
| Spindle Taper | 2Mt |
| Spindle To Column Distance | 10 1/2" |
| Spindle Travel | 3 1/8" |
| Swing | 12" |
| Table Length | 9 1/2" |
| Table Shape | Square |
| Table Slot | Yes |
| Table Slot Width | 5/8" |
| Table Tilt | 45 ° Left And Right |
| Table Width | 9 1/2" |
| Tilt Angle | 45° |
| Tool Weight | 85 lbs. |
| Voltage | 115V AC |
| Ship weight (kg) | 41.625 |
| Country of Origin | CN |
