| Item | General Purpose Motor |
| Bearings | Ball |
| Capacitor Required | No |
| Duty | Continuous |
| Efficiency Group | Standard |
| Frame | 56C |
| Frame Material | Rolled Steel |
| Full Load Amps | 8.6/4.3 |
| Hp | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Inverter Rated | No |
| Length Less Shaft | 8.875" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face/Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Clockwise, Counter Clockwise |
| Motor Thermal Protection | None |
| Nameplate Rpm | 1725 |
| Nominal Efficiency | 64% |
| Number Of Speeds | 1 |
| Overall Length | 11" |
| Phase | 1 |
| Rpm Group | 1701-1800 |
| Rpm Range | 1701-1800 |
| Service Factor | 1.15 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2.125" |
| Voltage | 115/230 |
| Warranty | 2 Years |
| Ship weight (kg) | 10.35 |
| Ship height (cm) | 24.13 |
| Ship length (cm) | 38.46 |
| Ship width (cm) | 25.88 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame Material | Full Load Amps | HP | Hz | Motor Mounting Position | Motor Thermal Protection | Nameplate RPM | Nominal Efficiency | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR46JN0087Y | Steel | 4.0-3.8/2.0-1.9 | 1/3 | 50/60 | All Angle | Manual | 1725/1425 | 70.2% | €711.34 | |
 |
5KCR46MN0055Y | Steel | 5.8-5.6/2.9-2.8 | 1/2 | 50/60 | All Angle | Manual | 1725/1425 | 74.0% | €788.94 | |
 |
5KCR46MN0055X | Rolled Steel | 5.8-5.6/2.9-2.8 | 1/2 | 50/60 | All Angle | Auto | 1725/1425 | 74.0% | €728.94 | |
 |
5KCR49PN0099X | Rolled Steel | 9.0-8.8/4.5-4.4 | 3/4 | 50/60 | All Angle | Auto | 1725/1425 | 75.2% | €865.34 | |
 |
5KCR49UN0106X | Rolled Steel | 11.8-11.4/5.9-5.7 | 1 | 50/60 | All Angle | Auto | 1725/1425 | 77.4% | €994.28 |
