| Blade Material | Brass |
| Body Length | 2.47" |
| Connection Orientation | Straight |
| Current Rating | 20A |
| Face Dia. | 1 21/25" |
| For Environment | Dry |
| For Maximum Cable Diameter | 0.78" |
| For Minimum Cable Diameter | 0.385" |
| Grade | Federal Grade |
| Grounding | Grounded |
| Housing Color | Black, White |
| Housing Material | Nylon |
| Hp Rating | 1 hp |
| Ip Rating | Not Rated |
| Max. Operating Temp. | 60°C |
| Max. Wire Size | 10 AWG |
| Midget Locking | No |
| Min. Operating Temp. | -40°C |
| Min. Wire Size | 16 AWG |
| Nema Plug Configuration | L5-20P |
| Number Of Blades | 3 |
| Number Of Poles | 2 |
| Outside Dia. | 2 2/25" |
| Phase | 1.0 |
| Polarized | Yes |
| Power Indicating Light | Yes |
| Resistance Properties | Chemical Resistant, Impact Resistant, Uv/Sunlight Resistant |
| Shrouded | No |
| Voltage Rating | 125V AC |
| Wire Connection Type | Screw Terminals |
| Wiring Style | Standard |
| Ship weight (kg) | 0.135 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
| Country of Origin | MX |
