| Connection Orientation | Straight |
| Contact Material | Brass |
| Cover Type | No Cover |
| Current Rating | 20A |
| Depth | 1.03" |
| Face Plate Height | 2.7" |
| Face Plate Width | 1.31" |
| Gfci | Yes |
| Grounding | Grounded |
| Housing Color | Light Almond |
| Housing Material | Polycarbonate |
| Hp Rating | 1 hp |
| Includes | Faceplate, Screws, Self Grounding Clip, Wallplate |
| Max. Operating Temp. | 66°C |
| Max. Wire Size | 10 AWG |
| Min. Operating Temp. | -35°C |
| Min. Wire Size | 14 AWG |
| Mount Hole Center-to-center Height | 3.27" |
| Mounting Hardware Included | Yes |
| Mounting Type | Flush |
| Nema Receptacle Configuration | 5-20R |
| Number Of Outlets | 2 |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Phase | Single |
| Polarized | No |
| Receptacle Type | Decorator Duplex |
| Reset Type | Automatic |
| Reverse Service | Yes |
| Self Testing | Yes |
| Surge Protection | Yes |
| Visual Indicator Lights | Power Connected |
| Voltage Rating | 125V AC |
| Wire Connection Location | Back, Side |
| Wire Connection Type | Screw Terminals |
| Ship weight (kg) | 0.1696 |
| Ship height (cm) | 10.69 |
| Ship length (cm) | 3.56 |
| Ship width (cm) | 2.54 |
| Country of Origin | CN |
