| 55% Thread Drill Size | 5.7 mm |
| 65% Thread Drill Size | 0.219" |
| 75% Thread Drill Size | 5.45 mm |
| Coolant Fed | Non Coolant Through |
| Drill Bit Size | 0.2129", 0.2152", 0.2175", 0.2198", 0.2222" |
| Extended Neck | Yes |
| Features | Bright, Efficient Chip Evacuation, Increased Wear Resistance, Spiral Flute, Steam Oxide Surface Treatment |
| Grade | Grade 107 |
| Helix Angle | 50° |
| Number Of Flutes | 3 |
| Overall Length | 2 1/2" |
| Primary Material Application | All Materials |
| Secondary Material Application | Aluminum, Cast Iron, Steel |
| Shank Dia. | 1/4" |
| Shank Length | 1.469" |
| Shank Type | Straight |
| Square Size | 0.19" |
| System Of Measurement | Fractional Inch |
| Tap Chamfer | Bottoming |
| Tap Finish | Bright |
| Tap Material | High Speed Steel |
| Tap Shank Standard | Ansi |
| Tap Style | Spiral Flute |
| Tap Thread Size | 1/4"-28 |
| Thread Direction | Right Hand |
| Thread Length | 5/8" |
| Thread Limit | H3 |
| Thread Limit / Class Of Fit | H3 |
| Thread Size | 1/4"-28 |
| Thread Standard | Unf |
| Threads Per Inch | 28 |
| Ship weight (kg) | 0.0135 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
