| Airflow @ 3.000 In Sp | 2500 CFM |
| Airflow @ 4.000 In Sp | 3500 CFM |
| Amps | 17.7/8.86A |
| Assembly | Fully Assembled |
| Bearing Type | Permanently Lubricated Ball, Sealed |
| Corrosion Resistance | Yes |
| Dba @ 5 Feet | 82 dBA |
| Discharge Position | Bottom Horizontal, Down Blast, Top Horizontal, Up Blast |
| Drive Type | Direct Drive |
| For Air Type | Clean Air, Contaminated, Damp, Dirty And Dusty, Emergency Smoke Control, High Temperature, Spark Resistant |
| Frequency | 50/60 Hz |
| Housing Height | 46" |
| Housing Material | Plastic |
| Housing Width | 29 1/2" |
| Includes | Motor Mounting Base |
| Inlet Dia. | 12 3/8" |
| Max. Ambient Temp. | -13°F |
| Max. Static Pressure | 6 in. wc |
| Maximum Fan Speed | 1725 RPM |
| Maximum Inlet Air Temperature | 140°F |
| Min. Ambient Temp. | -40°C |
| Minimum Fan Speed | 1725 RPM |
| Motor Enclosure | Explosion Proof |
| Motor Frame Designation | 112 |
| Motor Hp | 7 1/2 hp |
| Motor Speed | 1725 RPM |
| Mounting Hardware Included | Yes |
| Mounting Orientation | Multiposition |
| Nameplate Voltage | 230/460V AC |
| Number Of Discharge Positions | 2 |
| Number Of Inlet | 1 |
| Outlet Dia. | 12 3/8" |
| Outlet Shape | Round |
| Outlet Type | Non Flanged |
| Overall Depth | 31 1/2" |
| Overall Height | 46" |
| Overall Width | 29 1/2" |
| Overload Thermal Protection | Yes |
| Phase | 3 |
| Rotation | Counter Clockwise |
| Shaft Dia. | 28 mm |
| Spark Resistant Construction Type | A |
| Wheel Dia. | 14 5/8" |
| Wheel Material | Plastic |
| Wheel Type | Forward Curved |
| Wheel Width | 7" |
| Ship weight (kg) | 98.55 |
| Ship height (cm) | 117 |
| Ship length (cm) | 80.01 |
| Ship width (cm) | 74.93 |
| Country of Origin | US |
