Due to weight and dimension restrictions, please request a shipping quote
Payment Options Available
| Amps | 15/7.5A |
| Application | Drilling |
| Base Length | 13 1/2" |
| Base Width | 20 1/2" |
| Chuck Capacity | 5/8" |
| Chuck Size | 5/8" |
| Chuck Style | Keyed |
| Column Dia. | 3 1/8" |
| Coolant System | No |
| Drill Press Type | Floor Stand |
| Drilling Capacity In Stainless Steel | 1/2" |
| Drilling Capacity In Wood | 5/8" |
| Drilling Capacity Steel | 1/2" |
| Drive Type | Belt |
| Guard Included | No |
| Hp | 1 hp |
| Includes | Keyed Chuck |
| Length | 18" |
| Max. Overall Height | 71" |
| Max. Spindle Speed | 3000 RPM |
| Maximum Spindle To Base Height | 44 3/4" |
| Maximum Spindle To Table Height | 26 5/8" |
| Min. Spindle Speed | 250 RPM |
| Number Of Speeds | Variable |
| Number Of Spindle Speeds | Variable |
| Number Of T-slots | 0 |
| Phase | 1 |
| Power Downfeed Included | No |
| Power Source | Corded |
| Primary Material Application | Wood |
| Quill Dia. | 2.594" |
| Radial Arm | No |
| Speed Adjustment | Variable Speed Pulley |
| Speed Control | Variable |
| Speed Range | 250-3000 RPM |
| Spindle Taper | Mt2 |
| Spindle Travel | 6" |
| Swing | 18" |
| Table Length | 20 1/4" |
| Table Shape | Rectangular |
| Table Slot Width | 3/8" |
| Table Tilt | 90 ° Left And Right |
| Table Width | 14" |
| Tilt Angle | 90° |
| Voltage | 115/230V AC |
| Ship weight (kg) | 119.7 |
| Ship height (cm) | 180.34 |
| Ship length (cm) | 45.72 |
| Ship width (cm) | 51.44 |
| Country of Origin | CN |
