| Bore Dia. | 8 mm |
| Bore Tolerance | +0.05 mm to +0.012 mm |
| Bore Type | Round Keyed |
| Clearance Dia. | 22.4 mm |
| Collar Material | Stainless Steel |
| Collar Material Finish | Bright |
| Collar Width | 20 mm |
| Construction | Two Piece |
| For Shaft Dia. | 8 mm |
| Grade | Grade 303 |
| Included Screws | (4) Clamp Screw |
| Keyway Depth | 1.1 mm |
| Keyway Width | 2 mm |
| Max. Operating Temp. | 350°F |
| Min. Operating Temp. | -40°F |
| Outside Dia. | 18 mm |
| Resistance Properties | Corrosion Resistant |
| Screw Location From Center | 6.5 mm |
| Screw Material | Stainless Steel |
| Screw Material Finish | Bright |
| Screw Material Grade | Grade 18-8, 300 Series |
| Screw Seating Torque | 1.1 N-m |
| Screw Thread Size | M3 |
| Shaft Locking Type | Clamp On |
| Shaft Tolerance | -0.013 mm to 0 mm |
| System Of Measurement | Metric |
| Width Tolerance | -0.254 mm to +0.076 mm |
| Ship weight (kg) | 0.027 |
| Ship height (cm) | 2.36 |
| Ship length (cm) | 3.33 |
| Ship width (cm) | 3.33 |
| Country of Origin | US |
| Model | Bore Dia. | Clearance Dia. | Material | Outside Dia. | Screw Material | Screw Size | Width | Price | |
|---|---|---|---|---|---|---|---|---|---|
| WSP-10-F | 5/8" | 140.8mm | Black Oxide 1215 Lead Free Steel | 130mm | Alloy Steel | #10-32 | 32mm | €76.88 | |
| WSP-10-SS | 5/8" | 140.8mm | 303 Stainless Steel | 130mm | Stainless Steel | #10-32 | 32mm | €194.44 | |
| WSP-12-F | 3/4" | 149.9mm | Black Oxide 1215 Lead Free Steel | 140mm | Alloy Steel | 1/4"-28 | 32mm | €81.21 | |
| WSP-12-SS | 3/4" | 26.3mm | 303 Stainless Steel | 24mm | Stainless Steel | 1/4"-28 | 9mm | €193.90 | |
| WSP-14-F | 7/8" | 26.3mm | Black Oxide 1215 Lead Free Steel | 24mm | Alloy Steel | 1/4"-28 | 9mm | €98.29 | |
| WSP-14-SS | 7/8" | 32.0mm | 303 Stainless Steel | 28mm | Stainless Steel | 1/4"-28 | 11mm | €235.56 | |
| WSP-16-F | 1" | 32.0mm | Black Oxide 1215 Lead Free Steel | 28mm | Alloy Steel | 1/4"-28 | 11mm | €87.87 |
