| Accuracy Grade | Asme B40.100 Grade 1A |
| Accuracy Scale | Full Scale |
| Ambient Operating Temperature Range | -40°C to +120°C |
| Application | Compressors, Hydraulics, Oil And Gas Industry, Outdoor, Process Conditions, Process Industries, Pumps, Severe Ambient Conditions, Vibration Measurement |
| Bezel Gasket Material | Buna N |
| Bezel Material | Stainless Steel |
| Bezel Material Grade | Grade 304 |
| Bezel Mounting Type | Bayonet |
| Blowout Safety Back | Yes |
| Bolt Circle Dia. | 6.89" |
| Calibration Certificate Included | No |
| Case Color | Stainless Steel |
| Case Construction | Welded Joint |
| Case Dia. | 6.338" |
| Case Grade | Grade 304 |
| Case Material | Stainless Steel |
| Compatible Process Media | Oil |
| Dial Color | White |
| Dial Face Material | Aluminum |
| Field Fillable | Yes |
| Flange Dia. | 6" |
| Gauge Accuracy Grade | Grade 1A - Industrial |
| Gauge Wetted Parts | Stainless Steel |
| Includes | Restrictor Screw |
| Includes Vent Plug | No |
| Ip Rating, Nema Rating | Ip66, Nema 4X |
| Liquid-filled Case | No |
| Mfr. Series | Pfp |
| Mounting Type | Back Flange |
| Movement Material | Stainless Steel |
| Movement Material Grade | Grade 304 |
| Nominal Dial Size | 6" |
| Non-sparking | No |
| Panel Mount Characteristics | 3 0.240 In Dia Holes On 6.89 In Dia Bolt Circle |
| Panel-mountable | Yes |
| Pointer Characteristics | Micrometer Adjustable |
| Pointer Color | Black |
| Pointer Material | Aluminum |
| Pressure Gauge Type | Industrial Pressure Gauge |
| Pressure Range | 0.0 psi to 15.0 psi |
| Pressure Range Type | Pressure |
| Primary Pressure Range | 0 psi to 15 psi |
| Primary Scale Minor Graduations | 1, 5 |
| Primary Scale Numeric Increments | 3, 10 |
| Primary Scale Units | Psi |
| Process Connection Gender | Male |
| Process Connection Location | Bottom |
| Process Connection Size | 1/4" |
| Process Connection Type | Npt |
| Process Temperature Range | -40°F to +250°F |
| Removable Bezel | Yes |
| Scale Type | Dual |
| Secondary Pressure Range | 0 psi to 100 psi |
| Secondary Scale Units | Kpa |
| Sensor Grade | 316L Stainless Steel |
| Sensor Type | Bourdon Tube |
| Vibration Resistance | Field Fillable |
| Ship weight (kg) | 1.17 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 16.1 |
| Ship width (cm) | 16.1 |
| Country of Origin | CN |
