| Item | Submersible Sewage Pump |
| Amps | 9.4A |
| Base Material | Polypropylene |
| Bearing Type | Sleeve |
| Body Dia. | 11.333" |
| Body Material | Cast Iron |
| Cord Length | 9 ft. |
| Diameter | 4 22/25" |
| Discharge Npt | 2" |
| Discharge Size | 2"-NPT |
| Duty Cycle | Continuous |
| Flow Rate @ 10 Ft. Of Head | 60 GPM |
| Flow Rate @ 15 Ft. Of Head | 23 GPM |
| Flow Rate @ 5 Ft. Of Head | 90 GPM |
| Gpm Of Water @ 10 Ft. Of Head | 60 |
| Gpm Of Water @ 15 Ft. Of Head | 22 |
| Gpm Of Water @ 5 Ft. Of Head | 90 |
| Height | 14 3/4" |
| Housing | Cast Iron |
| Housing Material | Cast iron |
| Hp | 2/5 hp |
| Impeller Material | Thermoplastic |
| Max. Dia. Solids | 2" |
| Max. Head | 18 ft. |
| Max. Liquid Temp. | 130 Degrees F |
| Max. Solid Dia. | 2" |
| Max. Temp. | 130°F |
| Min. Sump Pit Dia. | 18" |
| Motor Rpm | 1725 |
| Motor Type | Permanent Split Capacitor, Hermetically-Sealed, Oil-Filled |
| Off Point | 4 1/2" |
| On Point | 12 1/2" |
| Outlet Size | 2" |
| Phase | 1 |
| Pump Type | Automatic |
| Rpm | 1725 RPM |
| Series | Waste-Mate 260 Series |
| Shaft Material | Carbon/Ceramic |
| Shaft Seal | Carbon/Ceramic |
| Shaft Seal Material | Carbon Ceramic |
| Switch Actuation | Vertical Float |
| Switch Electrical Connection | Integral |
| Switch Type | Vertical Float |
| Thermal Protection | Yes |
| Top Material | Cast Iron |
| Voltage | 115V AC |
| Warranty | 1 yr. |
| Ship weight (kg) | 15.39 |
| Ship height (cm) | 37.47 |
| Ship length (cm) | 34.54 |
| Ship width (cm) | 37.47 |
| HS code | 8413702004 |
| Country of Origin | US |
| Product | Model | Amps | Base Material | Bearing Type | Cord Length | Diameter | GPM of Water @ 10 Ft. of Head | GPM of Water @ 15 Ft. of Head | GPM of Water @ 20 Ft. of Head | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
M267 | 10.4 | 303 Stainless Steel | Oil Lubricated | 10ft. | 13 1/16" | 89 | 50 | 10 | €741.32 | |
 |
M282 | 10.3 | 303 Stainless Steel | Upper Sleeve and Lower Ball | 10ft. | 13 9/16" | 95 | 63 | 33 | €1,640.82 | |
|
D284 | 8.9 | 303 Stainless Steel | Upper Sleeve and Lower Ball | 20ft. | 13 9/16" | 157 | 133 | 106 | €1,869.55 | |
 |
M292 | 15 | 303 Stainless Steel | Ball | 20ft. | 12.875" | 124 | 108 | 91 | €1,939.54 | |
 |
N264 | 9.4 | Polypropylene | Sleeve | 15ft. | 4 22/25" | 60 | 22 | - | €611.73 | |
|
E264 | 4.7 | Polypropylene | Sleeve | 15ft. | 13.125" | 60 | 22 | - | €765.25 | |
 |
N267 | 10.4 | 303 Stainless Steel | Oil Lubricated | 15ft. | 13 1/16" | 89 | 50 | 10 | €806.62 |
