Pipe and Test Plugs

SHAW PLUGS -

Snap-Tite Mechanical Expansion Plugs, 0 to 1 Inch

A

B

C

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	51011	1"	0.969" To 1.07"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€40.68
A	51003	1/2"	0.468" To 0.515"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€27.89
A	51007	3/4"	0.719" To 0.791"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€38.10
B	51001	3/8"	0.375" To 0.413"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€21.43
A	51005	5/8"	0.612" To 0.673"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€31.62
A	51009	7/8"	0.85" To 0.935"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€41.00
B	51002	7/16"	0.406" To 0.447"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€24.04
A	51004	9/16"	0.55" To 0.605"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€28.57
C	51404	9/16"	0.55" To 0.605"	Up To 10 psi	Neoprene Rubber	Stainless Steel	Stainless Steel	Snap-Tite	€32.26
A	51006	11/16"	0.656" To 0.722"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€32.11
A	51008	13/16"	0.781" To 0.86"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€36.60
B	51010	31/32"	0.937" To 1.03"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€43.47

REAL-TITE PLUGS -

Countersunk Expansion Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPCS15	1.5"	1.64"	1.95"	1.8"	2.5"	€13.95	RFQ
A	RTPCS20	2"	2.09"	2.33"	1.8"	2.5"	€14.22	RFQ
A	RTPCS25	2.5"	2.72"	3.19"	2.8"	3.63"	€18.32	RFQ
A	RTPCS30	3"	3.04"	3.48"	2.85"	4"	€20.63	RFQ
A	RTPCS35	3.5"	3.82"	4.15"	2.9"	4.78"	€21.17	RFQ
A	RTPCS40	4"	4.2"	4.61"	2.9"	5.375"	€21.81	RFQ

CHERNE -

End-Of-Pipe Gripper Plugs

A

B

C

D

E

F

Style	Model	Nominal Size	Range	Max. Back Pressure	Length	Price (ex. VAT)
A	270210	1 1/2"	1.48" To 1.65"	17 psi/40 ft.	1.75"	€6.60
B	270229	2"	1.9" To 2.17"	17 psi/40 ft.	1.87"	€7.01
C	270237	3"	2.8" To 3.1"	17 psi/40 ft.	2.5"	€9.81
D	270245	4"	3.8" To 4.06"	17 psi/40 ft.	2.5"	€12.18
E	270261	6"	5.77" To 6.08"	17 psi/40 ft.	3.75"	€36.63
F	270270	8"	7.7" To 8.03"	17 psi/40 ft.	3.75"	€69.24

CHERNE -

Inside-Of-Pipe Gripper Plugs

A

B

Style	Model	Nominal Size	Range	Max. Back Pressure	Length	Material	Price (ex. VAT)
A	270296	4"	3.8" To 4.06"	17 psi/40 ft.	2.5"	ABS Plastic	€12.54
A	270253	6"	5.77" To 6.08"	17 psi/40 ft.	3.75"	ABS Plastic	€36.52
B	270288	8"	7.7" To 8.03"	17 psi/40 ft.	3.75"	ABS Plastic	€65.15

SHAW PLUGS -

Snap-Tite Mechanical Expansion Plugs, 1 to 2 Inch

A

B

C

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	51015	1.5"	1.380" To 1.518"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€59.24
B	51013	1.25"	1.190" To 1.309"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€56.13
A	51017	1.75"	1.630" To 1.793"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€64.24
C	51019	2"	1.950" To 2.165"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€74.99

REAL-TITE PLUGS -

Hex Head Expension Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPHH15	1.5"	1.64"	1.95"	2.02"	2.5"	€19.14	RFQ
A	RTPHH20	2"	2.09"	2.33"	2.03"	2.5"	€19.87	RFQ
A	RTPHH25	2.5"	2.72"	3.19"	2.51"	3.63"	€23.43	RFQ
A	RTPHH30	3"	3.04"	3.48"	2.31"	3.63"	€23.52	RFQ
A	RTPHH35	3.5"	3.82"	4.15"	2.68"	4.78"	€25.80	RFQ
A	RTPHH40	4"	4.2"	4.61"	2.39"	5.375"	€26.73	RFQ

REAL-TITE PLUGS -

Thumb Bolt Expension Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPTB15	1.5"	1.64"	1.95"	2.3"	2.5"	€18.35	RFQ
A	RTPTB20	2"	2.09"	2.33"	2.33"	2.5"	€18.71	RFQ
A	RTPTB25	2.5"	2.72"	3.19"	3.32"	3.63"	€23.07	RFQ
A	RTPTB30	3"	3.04"	3.48"	3.29"	4"	€23.16	RFQ
A	RTPTB35	3.5"	3.82"	4.15"	3.5"	4"	€23.88	RFQ
A	RTPTB40	4"	4.2"	4.61"	3.4"	4"	€25.28	RFQ

CHERNE -

I-Series Muni Ball Plugs

A

B

C

D

E

F

G

H

Style	Model	Deflated Diameter	Deflated Length	Item	Nominal Size	Range	Price (ex. VAT)
A	311088	-	-	Plug	-	-	€954.66
B	314728	-	-	Pipe Plug	-	-	€21,151.44	RFQ
C	614428	-	-	Plug	-	-	€8,480.23
D	613188	-	-	Plug	-	-	€3,344.10
E	614338	-	-	Plug	-	-	€6,660.54
F	316968	-	-	Plug	-	-	€30,929.58
A	312168	-	-	Plug	-	-	€1,553.82
G	214188	10.5"	25"	Muni ball plug	12" to 18"	10.75" To 18.25"	€2,435.58
H	312248	10.38"	37"	Muni ball plug	12" to 24"	11" To 24.25"	€2,528.06

SHAW PLUGS -

Snap-Tite Mechanical Expansion Plugs, 2 to 3 Inch

A

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	51023	2.5"	2.470" To 2.742"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€83.40
A	51021	2.25"	2.250" To 2.498"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€73.03
A	51025	2.75"	-	Up To 5 psi	Neoprene Rubber	Zinc Plated Steel	Brass	Snap-Tite	€82.86
A	51027	3"	2.940" To 3.263"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€90.92

REAL-TITE PLUGS -

Countersunk Chrome Hex Extension Expansion Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPCX15	1.5"	1.64"	1.95"	2.65"	2.5"	€30.26	RFQ
A	RTPCX20	2"	2.09"	2.33"	2.65"	2.5"	€30.47	RFQ
A	RTPCX25	2.5"	2.66"	2.95"	3.65"	3.63"	€38.81	RFQ
A	RTPCX30	3"	3.04"	3.5"	3.7"	4"	€39.47	RFQ
A	RTPCX35	3.5"	3.82"	4.15"	3.75"	4.78"	€40.02	RFQ
A	RTPCX40	4"	4.2"	4.61"	3.75"	5.375"	€47.66	RFQ

CHERNE -

I-Series Test-Ball Plugs

A

B

C

D

E

F

Style	Model	Nominal Size	Range	Max. Back Pressure	Required Inflation Pressure	Deflated Length	Deflated Diameter	Eye Inside Dia.	Price (ex. VAT)
A	310168	-	-	-	-	-	-	-	€1,095.04
A	310128	-	-	-	-	-	-	-	€957.83
B	310448	-	-	-	-	-	-	-	€7,040.08
A	310248	-	-	-	-	-	-	-	€1,868.32
C	310968	-	-	-	-	-	-	-	€23,918.38	RFQ
D	694248	-	-	-	-	-	-	-	€3,099.75
E	210128	8" to 12"	7.5 To 12.25"	15 psi	45 psi	19.8"	6.85"	0.25" Eyebolt	€1,092.22
F	210188	12" to 18"	10.75" To 18.25"	15 psi	45 psi	25"	10.5"	0.25" Eyebolt	€1,781.93

SHAW PLUGS -

Snap-Tite Mechanical Expansion Plugs, 3 to 4 Inch

A

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	51029	3.5"	3.380" To 3.752"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€96.21
A	51031	4"	3.940" To 4.373"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Snap-Tite	€89.51

REAL-TITE PLUGS -

Hex Extension Expension Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPHX15	1.5"	1.64"	1.95"	2.6"	2.5"	€33.32	RFQ
A	RTPHX20	2"	2.09"	2.33"	2.6"	2.5"	€33.61	RFQ
A	RTPHX25	2.5"	2.66"	2.95"	3.60"	3.63"	€36.10	RFQ
A	RTPHX30	3"	3.3"	3.5"	3.65"	4"	€36.31	RFQ
A	RTPHX35	3.5"	3.82"	4.15"	3.7"	4.78"	€37.12	RFQ
A	RTPHX40	4"	4.2"	4.61"	3.7"	5.375"	€38.13	RFQ

SHAW PLUGS -

Turn-Tite Mechanical Expansion Plugs, 0 to 1 Inch

A

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	52001	1"	0.937" To 1.031"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€52.32
A	52096	1/2"	0.48" To 0.528"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€45.87
A	52098	3/4"	0.719" To 0.791"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€53.27
A	52097	5/8"	0.6" To 0.672"	Up To 10 psi	Neoprene Rubber	Stainless Steel	Brass	Turn-Tite	€51.38
A	52099	7/8"	0.812" To 0.893"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€51.45

CHERNE -

Sure-Grip Plugs

A

Style	Model	Nominal Size	Range	Max. Back Pressure	Length	Material	Price (ex. VAT)
A	271158	1.5"	1.48" To 1.63"	22 psi/50 ft.	2.5"	Polypropylene	€6.11
A	271208	2"	1.89" To 2.09"	22 psi/50 ft.	3"	Polypropylene	€7.40
A	271308	3"	2.89" To 3.09"	13 psi/30 ft.	3.7"	Polypropylene	€8.18
A	271408	4"	3.87" To 4.09"	13 psi/30 ft.	3.5"	Polypropylene	€12.08

SHAW PLUGS -

Turn-Tite Mechanical Expansion Plugs, 1 to 2 Inch

A

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	52003	1.5"	1.440" To 1.584"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€59.46
A	52002	1.25"	1.210" To 1.331"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€52.38
A	52004	1.75"	1.7" To 1.87"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€65.37
A	52001-1	1.125"	1.06" To 1.166"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€48.43
A	52002-1	1.375"	1.320" To 1.452"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€54.98
A	52003-1	1.625"	1.55" To 1.705"	Up To 10 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€51.34
A	52004-1	1.875"	1.81" To 1.991"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€57.40
A	52005	2"	1.92" To 2.142"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€69.80

REAL-TITE PLUGS -

Countersunk Security Hooked Expansion Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPSH25	2.5"	4.72"	3.19"	2.72"	3.41"	€57.00	RFQ
A	RTPSH30	3"	3.04"	3.48"	2.9"	4"	€59.67	RFQ
A	RTPSH35	3.5"	3.82"	4.15"	2.3"	4.78"	€62.35	RFQ
A	RTPSH40	4"	4.2"	4.61"	2.9"	5.375"	€62.35	RFQ

REAL-TITE PLUGS -

Pinned Expansion Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Cover Outside Diameter	Bolt Length	Price (ex. VAT)
A	RTPSP25	2.5"	2.72"	3.19"	3.41"	3"	€37.40	RFQ
A	RTPSP30	3"	3.04"	3.48"	3.75"	3-1/2"	€38.29	RFQ
A	RTPSP35	3.5"	3.82"	4.15"	4.78"	3-1/2"	€41.85	RFQ
A	RTPSP40	4"	4.2"	4.61"	5.125"	3-1/2"	€42.75	RFQ

CHERNE -

Muni-Ball Plugs, Single Size

A

B

C

D

E

Style	Model	Deflated Diameter	Deflated Length	Nominal Size	Range	Price (ex. VAT)
A	262008	1.4"	3.8"	1.5"	1.49" To 1.88"	€202.83
A	262010	1.75"	6"	2"	1.88" To 2.25"	€201.18
B	262258	2.5"	8"	3"	2.62" To 3.25"	€288.97
A	262048	3.13"	8"	4"	3.25" To 4.25"	€224.00
C	262064	4.5"	7"	6"	4.5" To 6.25"	€282.57
D	262080	6.75"	10"	8"	7" To 8.25"	€350.67
A	262110	8.75"	11.75"	10"	9" To 10.25"	€443.28
A	262129	10.25"	13.75"	12"	10.5" To 12.25"	€606.52
E	262137	13.75"	19.75"	15" to 16"	14" To 16"	€1,005.40

SHAW PLUGS -

Turn-Tite Mechanical Expansion Plugs, 2 to 3 Inch

A

Style	Model	Nominal Size	Inside Dia.	Max. Air Pressure	Material	Body Material	Handle Material	Type	Price (ex. VAT)
A	52007	2.5"	2.44" To 2.708"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€65.00
A	52006	2.25"	2.22" To 2.464"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€53.78
A	52008	2.75"	2.63" To 2.919"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€63.56
A	52009	3"	2.92" To 3.241"	Up To 5 psi	Neoprene Rubber	Zinc-Plated Steel	Brass	Turn-Tite	€66.07

REAL-TITE PLUGS -

Countersunk Flush Chrome Expansion Plugs

A

Style	Model	Diameter	Inside Dia.	Seal Opening Inside Dia.	Length	Cover Outside Diameter	Price (ex. VAT)
A	RTPFC15	1.5"	1.64"	1.95"	1.85"	2.5"	€25.19	RFQ
A	RTPFC20	2"	2.09"	2.33"	1.85"	2.5"	€25.41	RFQ
A	RTPFC25	2.5"	2.72"	3.19"	2.85"	3.63"	€34.18	RFQ
A	RTPFC30	3"	3.04"	3.48"	2.9"	4"	€34.83	RFQ
A	RTPFC35	3.5"	3.82"	4.15"	2.9"	4.78"	€35.39	RFQ
A	RTPFC40	4"	4.2"	4.45"	2.9"	5.375"	€42.87	RFQ
