DESTACO 2007-UBR Vertical Hold Down Clamp, 1000 lb Holding Capacity

Destaco 2007-UBR vertical hold down clamp is suitable for holding down workpieces against flat surfaces / workbenches in woodworking and metalworking facilities. It features a U style clamping bar with a neoprene spindle for keeping the workpiece in position throughout the operation while preventing loosening and unwanted workpiece movement. It has carbon steel construction which is zinc plated for minimising damage / wear against abrasive conditions & outdoor environments. The clamp's U shaped bar is designed such that it enables quick spindle adjustment along the holding bar length. This feature ensures that the worker can adjust the toggle clamp for workpieces of varying sizes. This toggle clamp is a suitable choice for operations where there is a requirement to clamp / detach the workpiece repeatedly throughout the operation. It is a vertical hold down toggle locking clamp that is designed for ensuring a long life cycle when using a standard clamping arm and spindle. It comes with a straight style base for enabling secure installation on vertical surfaces / workbenches. However, this clamp is not recommended for machining and food & packaging applications. Destaco 2007 Series clampsare also available in flanged base U bar and flanged base solid bar variants on Raptor Supplies.

Uses:

Destaco 2007-UBR vertical hold down toggle locking clamp is ideal for assembly & testing operations, checking fixtures and woodworking & light machining applications.

Features:

• Destaco 2007-UBR vertical hold down clamp features a long clamping arm & handle for delivering maximum hand clearance.
• It features hardened bushings at key pivot points for durability.
• Destaco vertical hold down toggle locking clamp's bright coloured plastic handle ensures easy gripping and minimises user fatigue over prolonged use.
• Its neoprene spindle keeps the workpiece in place while ensuring near vertical clamping contact, thereby preventing workpiece from loosening / slipping.
• Destaco vertical hold down toggle locking clamp has carbon steel construction which is zinc plated for minimising damage / wear against abrasive conditions & outdoor environments.

Compatible Accessories:

• Destaco 2007208-M flat tip bonded neoprene spindle is used for replacing the broken / worn out spindle on Destaco 2007-UBR vertical hold down toggle locking clamp.
• Destaco 507107 flanged washer is used to maintain sufficient load for tightening bolts & gaskets of a flange.

Standards and Approvals:

• Destaco 2007-UBR vertical hold down toggle locking clamp is manufactured in compliance with ISO 9001:2015 & ISO 14001:2015 international industry standards.

Installation:

• Destaco 2007-UBR vertical hold down toggle locking clamp features straight style base for enabling easy installation on vertical surfaces / workbenches.

Frequently Asked Questions:

Q. Does the brand offer vertical hold down clamps in other base mounting styles?

A. Yes, in addition to Destaco 207-UBR straight base U bar variant, the brand also offers flanged base U bar (Destaco 2007-U) and flanged base solid bar (Destaco 2007-S) vertical clamps as well.

Q. What does holding capacity mean in terms of clamps?

A. The holding force or the holding capacity depicts the clamp's capability to hold down the equipment or a sheet metal on assembly lines or during similar manufacturing processes.

Q. What is a vertical hold down clamp?

A. Destaco vertical hold down clamps are specially designed clamps that are used for holding the workpiece stationary against a flat surface / workbench and are ideal for various industrial applications like woodworking & metalworking.

Q. What does clamping force mean?

A. Clamping force is the amount of force actually applied to a workpiece by closing & locking the clamp. It is normally less than the stated holding capacity. The actual clamping force depends on various factors, including cylinder bore, cylinder area, spindle position (clamping arm length) and available air pressure. In most cases, the clamping force is approximately 2 to 3 times the force exerted by a pneumatic cylinder.

Q. Does the brand offer vertical hold down clamps in other configurations?

A. Destaco also offers a wide variety of vertical hold down clamps in a range of configurations & styles, such as J hook style clamping arm, low profile T style handle & Toggle Lock Plus enabled clamps.

Q. What is the difference between a vertical & horizontal toggle clamp?

A. The difference lies in the orientation of the handle when the clamp is in the locked position. A vertical clamp handle is oriented perpendicular to the base when in locked position, while in the case of a horizontal toggle clamp, it is oriented parallel to the base.

Q. How do vertical hold down clamps work?

A. Some U bar style clamps, such as Destaco 2007-UBR, feature a flat tip bonded neoprene spindle that is manually operated using a handle / lever. This handle movement pushes the spindle against the workpiece and prevents it from moving mid operation, thereby ensuring secure clamping.

Q. Which grease is recommended for use with Destaco clamps when rebuilding?

A. Whenever you're dealing with the brand's mechanical clamps, it is recommended to use a coupling grease like Mobil XTC.

Q. Are Destaco clamps rust resistant?

A. Yes, carbon steel clamps from Destaco are zinc plated for withstanding & minimising wear against harsh industrial environments. For applications that require clamping in outdoor conditions, stainless steel variants are also available.
